| Product | USB Powered | USB Type | Voltage | Internal Diameter | External Diameter | Length | Polarity | Included | |||
| AudioFuse Rev1 | YES but limited mode | Specific Micro USB to 2x USB A | 18V DC 1600mA | 1.35mm | 3.5mm | 9mm | Center Positive | YES | |||
| AudioFuse Rev2 | YES but limited mode | Specific Micro USB to 2x USB A | 18V DC 1600mA | 1.35mm | 3.5mm | 9mm | Center Positive | YES | |||
| AudioFuse Studio | YES but limited mode | USB-C | 15V DC 3A | 2.5mm | 5.5mm | 10mm | Center Positive | YES | |||
| AudioFuse 8Pre | NO | USB-C | 15V DC 2A | 2.5mm | 5.5mm | 7.5mm | Center Positive | YES | |||
| AudioFuse 16Rig | NO | USB-C | 15V DC 3A | 2.5mm | 5.5mm | 10mm | Center Positive | YES | |||
| AudioFuse X8 IN/OUT | NO | HIDDEN | 15V DC 2A | 2.5mm | 5.5mm | 10mm | Center Positive | YES | |||
| MiniFuse 4 | YES but limited mode | USB-C | 15V DC 1A | 1.35mm | 3.5mm | 10mm | Center Positive | YES | |||
| Product | USB Powered | USB Type | Voltage | Internal Diameter | External Diameter | Length | Polarity | Included | |||
| DrumBrute | NO | USB B | 12V DC 1A | 2.1mm | 5.5mm | 10mm | Center Positive | YES | |||
| DrumBrute Impact | NO | USB B | 12V DC 1A | 2.1mm | 5.5mm | 10mm | Center Positive | YES | |||
| MiniBrute | NO | USB B | 12V DC 1A | 2.1mm | 5.5mm | 12mm | Center Positive | YES | |||
| MiniBrute 2 | NO | USB B | 12V DC 2500mA | 2.1mm | 5.5mm | 10mm | Center Positive | YES | |||
| MiniBrute 2S | NO | USB B | 12V DC 2500mA | 2.1mm | 5.5mm | 10mm | Center Positive | YES | |||
| MicroBrute | NO | USB B | 12V DC 1A | 2.1mm | 5.5mm | 12mm | Center Positive | YES | |||
| RackBrute 3U | NO | - | 15V DC 3A | 2.5mm | 5.5mm | 12mm | Center Positive | YES | |||
| RackBrute 6U | NO | - | 15V DC 3A | 2.5mm | 5.5mm | 12mm | Center Positive | YES | |||
| MatrixBrute | NO | USB B | Schuko | - | - | - | - | YES | |||
| PolyBrute | NO | USB B | Schuko | - | - | - | - | YES | |||
| PolyBrute12 | NO | USB B | Schuko | - | - | - | - | YES | |||
| MicroFreak / Vocoder | YES | USB B | 12V DC 1A | 2.1mm | 5.5mm | 10mm | Center Positive | YES | |||
| MiniFreak | NO | USB B | 12V DC 1A | 2.1mm | 5.5mm | 10mm | Center Positive | YES | |||
| AstroLab | NO | USB A host / USB C device | 12.0V DC / 3.0A | 2.5mm | 5.5mm | 10.3mm | Center Positive | YES | |||
| Product | USB Powered | USB Type | Voltage | Internal Diameter | External Diameter | Length | Polarity | Included | |||
| KeyLab Essential | YES | USB B | 9V DC 500mA | 2.1mm | 5.5mm | 12mm | Center Positive | NO | |||
| KeyLab Essential mk3 | YES | USB C | 5V DC 500mA | - | - | - | - | NO | |||
| KeyLab 25/49/61 MKI | YES | USB B | 5V DC 500mA | 2.1mm | 5.5mm | 12mm | Center Positive | NO | |||
| KeyLab 49/61 MKII | YES | USB B | 9-12V DC 1A | 2.1mm | 5.5mm | 10mm | Center Positive | NO | |||
| KeyLab 49/61 mk3 | YES | USB C | 12V DC 1A | 2.1mm | 5.5mm | 10mm | Center Positive | NO | |||
| KeyLab 88 MKI | YES | USB B | 6.5V DC 500mA | 2.1mm | 5.5mm | 12mm | Center Positive | NO | |||
| KeyLab 88 MKII | YES | USB B | 9-12V DC 1A | 2.1mm | 5.5mm | 10mm | Center Positive | NO | |||
| MicroLab | YES | USB B | 5V DC 500mA | - | - | - | - | NO | |||
| MiniLab MKI | YES | USB B | 5V DC 500mA | - | - | - | - | NO | |||
| MiniLab MKII | YES | USB B | 5V DC 500mA | - | - | - | - | NO | |||
| MiniLab 3 | YES | USB C | 5V DC 500mA | - | - | - | - | NO | |||
| KeyLab mk3 | YES | USB C | 12.0V DC / 1.0A | 2.1mm | 5.5mm | 10mm | Center Positive | NO | |||
| Product | USB Powered | USB Type | Voltage | Internal Diameter | External Diameter | Length | Polarity | Included | |||
| BeatStep | YES | Mini USB | 5V DC 500mA | - | - | - | - | NO | |||
| BeatStep Pro | YES | Micro USB | 5V DC 500mA | - | - | - | - | NO | |||
| KeyStep | YES | Micro USB | 9V DC 500mA | 2.1mm | 5.5mm | 10mm | Center Positive | NO | |||
| KeyStep 37 | YES | USB B | 12V DC 1500mA | 2.1mm | 5.5mm | 10mm | Center Positive | NO | |||
| KeyStep Pro | YES | USB B | 12V DC 1A | 2.1mm | 5.5mm | 10mm | Center Positive | YES | |||
| Product | Voltage | Internal Diameter | External Diameter | Length | Polarity | |
| Analog Experience | 6 to 12V DC 500mA* | 2.1mm* | 5.5mm* | 12mm* | Center Positive* | |
| Origin | 6.5V DC 3850mA | 2.1mm | 5.5mm | 12mm | Center Positive | |
| Spark | 9V DC 800mA | 2.5mm | 5.5mm | 12mm | Center Positive |
* Depending on the information printed on the back of the unit.
